Electric Linear Motion Actuator 12V DC Motor 1500N 330LB Load - DHLA750-A1
$15.00
Note: The stroke can be customized such as 650MM, 70MM, etc., And it will take 3-7 days. TECHNICAL PARAMETERS Voltage DC12V Speed (MM/S) 5 10 20 30 50 90 Load Pull Capacity(N) 1500 1000 500 300 200 100 Load Push Capacity(N) 1500 1000 500 300 200 100 Self-locking Capacity(N) 1000...
Note: The stroke can be customized such as 650MM, 70MM, etc., And it will take 3-7 days.
TECHNICAL PARAMETERS
|
Voltage
|
DC12V
|
|||||
|
Speed (MM/S)
|
5 | 10 | 20 | 30 | 50 | 90 |
|
Load Pull Capacity(N)
|
1500 | 1000 | 500 | 300 | 200 | 100 |
|
Load Push Capacity(N)
|
1500 | 1000 | 500 | 300 | 200 | 100 |
|
Self-locking Capacity(N)
|
1000 | 700 | 350 | 200 | 150 | 70 |
|
Stroke Length
|
30MM~800MM
|
|||||
|
Motor Power
|
20W
|
|||||
|
Operating Temperature
|
-0°C~+40°C
|
|||||
|
Limit Switches
|
Built-in
|
|||||
|
Operating Frequency
|
10% Max 2Min. Continuous Use
|
|||||
|
Inner Tube
|
Aluminum tube
|
|||||
|
Material
|
Aluminum
|
|||||
|
Lead Screw Type
|
Type T
|
|||||
|
Noise
|
45~60dB
|
|||||
|
Mechanical Life
|
More than 30,000 times
|
|||||
OUTLINE DIMENSION DRAWING
Optional Configuration
